Forklift Alternator

Forklift Alternators - A device used to be able to change mechanical energy into electrical energy is called an alternator. It can carry out this function in the form of an electric current. An AC electrical generator can in principal also be labeled an alternator. Then again, the word is normally used to refer to a small, rotating machine powered by internal combustion engines. Alternators that are situated in power stations and are driven by steam turbines are actually referred to as turbo-alternators. The majority of these machines use a rotating magnetic field but sometimes linear alternators are likewise utilized.

If the magnetic field surrounding a conductor changes, a current is induced inside the conductor and this is the way alternators generate their electrical energy. Usually the rotor, which is a rotating magnet, turns within a stationary set of conductors wound in coils located on an iron core which is actually referred to as the stator. If the field cuts across the conductors, an induced electromagnetic field or EMF is generated as the mechanical input causes the rotor to revolve. This rotating magnetic field generates an AC voltage in the stator windings. Usually, there are 3 sets of stator windings. These physically offset so that the rotating magnetic field induces 3 phase currents, displaced by one-third of a period with respect to each other.

In a "brushless" alternator, the rotor magnetic field could be made by induction of a lasting magnet or by a rotor winding energized with direct current through slip rings and brushes. Brushless AC generators are normally located in larger devices than those used in automotive applications. A rotor magnetic field may be induced by a stationary field winding with moving poles in the rotor. Automotive alternators usually use a rotor winding which allows control of the voltage generated by the alternator. This is done by varying the current in the rotor field winding. Permanent magnet devices avoid the loss because of the magnetizing current within the rotor. These machines are restricted in size because of the cost of the magnet material. The terminal voltage varies with the speed of the generator as the permanent magnet field is constant.
