Pinions for Forklift

Forklift Pinion - The main axis, known as the king pin, is found in the steering machinery of a lift truck. The very first design was a steel pin which the movable steerable wheel was connected to the suspension. As it could freely rotate on a single axis, it limited the degrees of freedom of motion of the remainder of the front suspension. In the 1950s, the time its bearings were substituted by ball joints, more comprehensive suspension designs became available to designers. King pin suspensions are still featured on some heavy trucks for the reason that they have the advantage of being capable of lifting much heavier cargo.

Newer designs no longer restrict this particular device to moving similar to a pin and now, the term may not be utilized for a real pin but for the axis in the vicinity of which the steered wheels revolve.

The KPI or otherwise known as kingpin inclination could also be known as the steering axis inclination or SAI. These terms describe the kingpin if it is set at an angle relative to the true vertical line as viewed from the front or back of the forklift. This has a major effect on the steering, making it likely to return to the straight ahead or center position. The centre position is where the wheel is at its peak point relative to the suspended body of the forklift. The motor vehicles weight tends to turn the king pin to this position.

One more impact of the kingpin inclination is to set the scrub radius of the steered wheel. The scrub radius is the offset among the projected axis of the steering down through the kingpin and the tire's contact point with the road surface. If these points coincide, the scrub radius is defined as zero. Although a zero scrub radius is possible without an inclined king pin, it requires a deeply dished wheel so as to maintain that the king pin is at the centerline of the wheel. It is more sensible to tilt the king pin and utilize a less dished wheel. This likewise supplies the self-centering effect.
